產品概述

APT32F110X系列

APT32F110由愛普特微電子推出的基于RISC CPU內核開發的32位高性能高可靠性單片機。 APT32F110系列單片機面向的應用為家電以及便攜設備等。

產品型號表


APT32F1101系列


Part NO. Op.Volt Temp Freq Pin GPIO Flash RAM Dflash HWD DMA IWDT WWDT BT CNTA RTC LPT EPT GPTA GPTB UART USART IIC SPI HSIO SIO PWM ADC CMP LED Driver Deep Sleep Shut Down PACKAGE
APT32F1101C8T6 1.8v~5.5v -40~85 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 10comx8seg 10uA 1.5uA LQFP48
APT32F1101C8T8 1.8v~5.5v -40~105 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 10comx8seg 10uA 1.5uA LQFP48
APT32F1101C8U6 1.8v~5.5v -40~85 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 10comx8seg 10uA 1.5uA QFN48
APT32F1101C8U8 1.8v~5.5v -40~105 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 10comx8seg 10uA 1.5uA QFN48


APT32F1103系列


Part NO. Op.Volt Temp Freq Pin GPIO Flash RAM Dflash HWD DMA IWDT WWDT BT CNTA RTC LPT EPT GPTA GPTB UART USART IIC SPI SIO HSIO PWM ADC CMP Touch LED Driver LCD Deep Sleep Shut Down PACKAGE
APT32F1103C8T6 1.8v~5.5v -40~85 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 32ch 10comx8seg 8comx26seg4comx30seg 10uA 1.5uA LQFP48
APT32F1103C8T8 1.8v~5.5v -40~105 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 32ch 10comx8seg 8comx26seg4comx30seg 10uA 1.5uA LQFP48
APT32F1103C8U6 1.8v~5.5v -40~85 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 32ch 10comx8seg 8comx26seg4comx30seg 10uA 1.5uA QFN48
APT32F1103C8U8 1.8v~5.5v -40~105 48MHz 48 44 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 32ch 10comx8seg 8comx26seg4comx30seg 10uA 1.5uA QFN48
APT32F1103S8T6 1.8v~5.5v -40~85 48MHz 44 41 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx17ch 2 30ch 10comx8seg 8comx24seg4comx28seg 10uA 1.5uA LQFP44
APT32F1103S8T8 1.8v~5.5v -40~105 48MHz 44 41 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx17ch 2 30ch 10comx8seg 8comx24seg4comx28seg 10uA 1.5uA LQFP44
APT32F1103K8T6 1.8v~5.5v -40~85 48MHz 32 29 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 6 16bitx18ch 12bitx12ch 2 20ch 6comx8seg 8comx15seg4comx19seg 10uA 1.5uA LQFP32
APT32F1103K8T8 1.8v~5.5v -40~105 48MHz 32 29 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 6 16bitx18ch 12bitx12ch 2 20ch 6comx8seg 8comx15seg4comx19seg 10uA 1.5uA LQFP32
APT32F1103K8U6 1.8v~5.5v -40~85 48MHz 32 29 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 6 16bitx18ch 12bitx12ch 2 20ch 6comx8seg 8comx15seg4comx19seg 10uA 1.5uA QFN32
APT32F1103K8U8 1.8v~5.5v -40~105 48MHz 32 29 64k 8k+0.25K 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 6 16bitx18ch 12bitx12ch 2 20ch 6comx8seg 8comX15seg4comx19seg 10uA 1.5uA QFN32


APT32F1104系列


Part NO. Op.Volt Temp Freq Pin GPIO Flash RAM Dflash HWD DMA IWDT WWDT BT CNTA RTC LPT EPT GPTA GPTB UART USART IIC SPI SIO HSIO PWM ADC CMP LCD Deep Sleep Shut Down PACKAGE
APT32F1104C8T6 1.8v~5.5v -40~85 48MHz 48 44 64k 8k+0.25k 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 8comx26seg 4comx30seg 10uA 1.5uA LQFP48
APT32F1104C8T8 1.8v~5.5v -40~105 48MHz 48 44 64k 8k+0.25k 2k √ 4ch 1 1 2 1 1 1 1 2 2 3 1 1 1 1 10 16bitx18ch 12bitx19ch 2 8comx26seg 4comx30seg 10uA 1.5uA LQFP48
